4K Seamless Multi-Function Matrix and Splicing Processor with Multiview
VIS-UHD0809-M-VW
4K matrix switching with multiview
Flexible video wall layouts (PIP, POP, 3×3)
EDID management & input clipping
Multi-control options with Web GUI & presets
Overview
The VIS-UHD0809-M-VW is a professional seamless UHD video matrix switcher and stitching processor with 8 HDMI inputs and 9 outputs. It supports resolutions up to 4K@60, 4:4:4, offers ultra-high data transmission rates, and allows creative video wall layouts via an intuitive Web GUI, based on a pure FPGA hardware architecture.
Features
● 8 HDMI inputs and 9 HDMI outputs with real-time seamless switching;
● 8 IR and 8 analog audio inputs, along with 9 IR and 9 analog audio outputs;
● The 9th output port seamlessly switches between video wall and multi-screen modes;
● The system supports PIP, quad split, 3x3 grid, and POP configurations. POP offers customizable modes like 1 large 7 small, 1 large 5 small, and 1 large 3 small screens, ideal for input monitoring or multi-participant conferences;
● Input and output support up to 4K@60, 4:4:4, compatible with HDMI 2.0 and HDCP 2.2;
● Intelligent analysis that automatically analyzes the EDID of display devices to output the best resolution;
● EDID management: select from built-in files, read from output devices, update EDID;
● Supports input image clipping, allowing part of the input image to be displayed as a signal;
● Supports adding logos to input images;
● Built-in signal generator with 11 professional test images on input and output channels;
● Outputs can be configured for seamless matrix output or single-layer stitching output;
● Supports synchronized stitching for LED or LCD large screens, with a maximum of 3x3 or 2x4 configurations;
● Supports scrolling subtitles on stitched large screens;
● Independent switching for audio and infrared;
● Supports graphical software control;
● Input volume controls adjustable channels and mute button;
● Multiple control methods: front panel, RS232, TCP/IP software, web control;
● Supports multiple flexible stitching configurations for any port to meet various application needs;
● Supports DHCP, with the ability to enable or disable via software or front panel;
● Various output modes available, including full screen and proportional scaling;
● Supports one-button freeze/unfreeze for output images;
● Intelligent management that shows real-time input signal status and output connection status on software;
● Adjustable HDCP version for inputs;
● One-button output screen on/off;
● Supports multi-user management with customizable permissions and port control;
● Supports preset management with one-button save/recall;
● Supports seam settings to compensate for gaps during screen stitching
